EN-43
[Tv] Shutter Speed Priority Photography Mode
In this mode, images are captured with the priority given to shutter speed. The aperture is automatically
set according to the shutter speed. If you set a fast shutter speed, you can capture images of moving
subjects that look as if they are still. If you set a slow shutter speed, you can capture images that give
the impression that the subject is in motion.
1. Slide the mode switch to [
] and set the mode dial to [ Tv].
2. Adjust the shutter speed with the S / T buttons.
J
Press the S button to select faster shutter speeds.
J
Press the T button to select slower shutter speeds.
J
The setting range of the shutter speed is as follows:
1/1500, 1/1250, 1/1000, 1/820, 1/650,1/500, 1/400, 1/320,
1/250, 1/200,1/160, 1/125, 1/100, 1/80, 1/64, 1/50,1/40, 1/32,
1/25, 1/20, 1/16, 1/13, 1/10, 0.13s, 0.16s, 0.2s, 0.25s, 0.3s,
0.4s, 0.5s, 0.6s, 0.8s, 1.0s.
J
The shutter speed and corresponding aperture value
ardisplayed on the screen. If an appropriate combination
cannot be set, the aperture value is displayed in red, but
images can be captured regardless.
3. Compose the image, press the shutter button down halfway,
and then press it down fully.
J
In the flash photography mode, when [ ] and [ ] are set, the fastest shutter speed is 1/500
second.
EN-43
[Tv] Shutter Speed Priority Photography Mode
In this mode, images are captured with the priority given to shutter speed. The aperture is automatically
set according to the shutter speed. If you set a fast shutter speed, you can capture images of moving
subjects that look as if they are still. If you set a slow shutter speed, you can capture images that give
the impression that the subject is in motion.
1. Slide the mode switch to [
] and set the mode dial to [ Tv].
2. Adjust the shutter speed with the S / T buttons.
J
Press the S button to select faster shutter speeds.
J
Press the T button to select slower shutter speeds.
J
The setting range of the shutter speed is as follows:
1/1500, 1/1250, 1/1000, 1/820, 1/650,1/500, 1/400, 1/320,
1/250, 1/200,1/160, 1/125, 1/100, 1/80, 1/64, 1/50,1/40, 1/32,
1/25, 1/20, 1/16, 1/13, 1/10, 0.13s, 0.16s, 0.2s, 0.25s, 0.3s,
0.4s, 0.5s, 0.6s, 0.8s, 1.0s.
J
The shutter speed and corresponding aperture value
ardisplayed on the screen. If an appropriate combination
cannot be set, the aperture value is displayed in red, but
images can be captured regardless.
3. Compose the image, press the shutter button down halfway,
and then press it down fully.
J
In the flash photography mode, when [ ] and [ ] are set, the fastest shutter speed is 1/500
second.
EN-45
[M] Manual Mode
In manual mode, the aperture value and the shutter speed can be varied individually.
1. Slide the mode switch to [
] and set the mode dial to [ M].
2. Toggle the button to select the shutter speed or aperture.
3. Adjust the shutter speed or aperture with the S / T buttons.
4. Compose the image, press the shutter button down halfway,
and then press it down fully.
J
In the flash photography mode, when [ ] and [ ] are set, the fastest shutter speed is 1/500
second.
Примечание
При съемке со вспышкой, когда установен или наименьшее значение выдержки
составляет 1/500 с.
[Tv] Фоторежим приоритета выдержки
В этом режиме съемка происходит с приоритетом выдержки. Диафрагма
автоматически устанавливается соответственно выдержки. Если Вы устанавливаете
маленькую выдержку, Вы может получить изображения, которые перемещаются как
неподвижные. Если Вы устанавливаете большую выдержку, Вы можете получить
изображение с эффектом движения.
1. Установите переключатель режимов и шкалу режимов в положение [Tv]
2. Установите значене выдержки кнопками
Компонуйте изображения, нажимайте кнопку спуска.
Нажмите чтобы увеличить значение выдержки.
Нажмите чтобы уменьшить значение выдержки.
3. Диапазон значений параметров выдержки такой:
1/1500, 1/1250, 1/1000, 1/820, 1/650, 1/500, 1/400, 1/320, 1/250, 1/200, 1/160,
1/125, 1/100,1/80, 1/64, 1/50, 1/40, 1/32, 1/25, 1/20, 1/16, 1/13, 1/10. 0.13с,
0.16с, 0.2с, 0.25с, 0.3с, 0.4с, 0.5с.
4. Компонуйте изображения, нажимайте кнопку спуска частично а потом
полностью.
•
•
•
