E13
Setting the shuttle memory position
Zoom to the position to be set. Keeping this position, press
the Shtl switch while holding down the MEMO switch.
1.The position you stored here is different from the one
you set in
“
Framing Preset
”
mentioned later. The stored
position set here is retained even after the power is
turned off.
2.The operation with the Shtl switch is given the priority
over that with the zoom rocker seesaw. The operation
with the zoom rocker seesaw is disabled while the Shtl
switch is pressed.
Before using shuttle-shot function, the shuttle function must be assigned to the VTR, RET, or AUX
switch of the drive unit, or the AUX1 or AUX2 switch on the zoom demand. This manual describes the
Shtl function assigned to the VTR switch. For details, refer to "5-6 SWITCH OPERATIONS".
5-1-5. Shuttle-Shot Function
This function allows you to switch between the current zoom position and the preset zoom position at
the maximum speed.
Zoom Rocker Seesaw
MEMO Switch
Shtl Switch
5-1-6. Speed Preset
This function allows you to call the preset zoom speed any time you zoom. Assign the Sped function
to the VTR, RET, or AUX switch of the drive unit, or AUX1 or AUX2 switch on the zoom demand. This
manual describes the Sped function assigned to the VTR switch.
1.
Storing the zoom speed and direction
Operate the zoom rocker seesaw to determine the zoom
speed and direction (toward the telephoto angle or the wid-
est angle) which you want to store, and press the MEMO
switch while holding this position.
The stored zoom speed is applied to the Framing Pre
-
set.
Zoom Rocker Seesaw
Sped Switch
MEMO
Switch
Current zoom position
Shuttle memory position
Previous zoom position
The Shtl
switch is
held down.
The Shtl
switch is
released.
Max
speed
Max
speed
5 OPERATION
