3
Once the hob has been installed, it is
important to remove any protective materials,
which were put on in the factory.
Hob burners control knobs
The hob burners control knobs are situated on the hob
right hand side. The symbols on the knobs mean that:
there is no gas supply
there is maximum gas supply
there is minimum gas supply
Lighting the burners
For easier lighting, proceed before putting a
pan on the pan support.
Models with semi-automatic ignition
To light a burner, depress the relevant switch
marked with a small spark. Then, push in the
relevant knob and turn it anticlockwise to "maximum
position" (ZGL 646 I).
Contents
This appliance complies with the following
E.E.C. Directives:
- 2006/95 (Low Voltage Directive);
- 89/336 (Electromagnetical Compatibility Directive);
- 93/68 (General Directives)
and subsequent modifications.
MANUFACTURER:
ELECTROLUX HOME PRODUCTS ITALY S.p.A.
Viale Bologna, 298
47100 FORLÌ (Italy)
For the User For the Installer
Instruction for the User
Important Safety Information 2
Instruction for the User 3
Cleaning and Maintenance 5
Technical Data 6
Instruction for the Installer 6
Electrical Connection 7
Adaptation to different types of gas 8
Building In 9
Possibilities for insertion 10
Fig. 2
A - Burner cap
B - Burner crown
C - Ignition candle
D - Thermocouple
! ! ! ! !
•
Fig. 1
The following symbols will be found in the text to guide
you throughout the Instructions:
Safety Instructions
Step by step instructions for an operation
Hints and Tips
Environmental information
Guide to Use the instructions
! ! ! ! !
