4
not switch on.
Never try to replace the parts and repair
the unit by yourself.
FOR THE FIRST TIME
Check that voltage, indicated on the
rating label, corresponds the mains
voltage in your home.
Wash all parts (except body) in warm
soapy water.
Before plugging in, ensure the “ON/OFF/
Reverse switch is turned to "OFF" posi-
tion.
INSTRUCTION FOR USE
ASSEMBLING
§ Holding the head, insert it in the inlet
with one hand, place the locking knob
into the hole on the side of the motor
housing. Tighten it clockwise to secure
the head (fig. 1-2).
§ Place the feed screw into the head,
long end first, by turning the feed screw
slightly until it is set into the motor
housing (fig.3).
§ Place the cutting blade onto the feed
screw shaft with the blade facing the
front as illustrated (fig.4). If it is not
fitted properly, meat will not be ground.
§ Place the desired cutting plate next
to the cutting blade, fitting protrusions
in the slots (fig.5).
§ Support or press the centre of the
cutting plate with one finger, then screw
the fixing ring until tight with another
hand (fig.6).
§ Do not over tighten. Place the hop-
per plate on the head and fix into posi-
tion.
§ Locate the unit on a firm place.
§ The air passage at the bottom and
the side of the motor housing should be
kept free and not blocked.
MINCING MEAT
u Cut all foods into pieces (sinew-
less, boneless and fatless meat is rec-
ommended, approximate size: 20 mm x
20 mm x 60 mm), so that they fit easily
into the hopper opening.
u Plug in and turn the “R / ON”
switch to "ON" position, then turn the
“ON/OFF/Reverse switch to "ON" posi-
tion.
u Feed foods into the hopper plate.
Use only the food pusher (fig.7).
u After use switch the unit off and
unplug it from the power supply.
REVERSE FUNCTION
u In case of jamming switch the
appliance off by turning the “R / ON”
switch to "R" position and “ON/OFF/
Reverse switch to "R" position.
u Feed screw will be rotating in the
opposite direction, and the head will get
empty.
u If it doesn't work, switch the unit
off and clean it.
MAKING KEBBE
RECIPE
STUFFING
Mutton
Olive oil
Onion (cut fine-
ly)
Spices
Salt
Flour
100g
1 1/tablespoons
1 1/tablespoons
to your taste
to your taste
1 1/tablespoons
u Mince mutton once or twice.
u Fry onion until brown and add
minced mutton, all spice, salt and
flour.
OUTLET COVER
Lean meat
Flour
Spices
Nutmeg (cut
finely)
450g
150-200g
to your taste
1
to your taste
5
Powdered red
pepper
u Mince meat three times and mix all
ingredients together in a bowl. More
meat and less flour for outlet cover cre-
ates better consistency and taste.
u Grind the mixture three times.
u Disassemble by reversing the steps
from 5-3 to remove the cutting plate
and cutting blade.
u Place kebbe attachments onto the
feed screw shaft together, fitting protru-
sions in the slots (fig.8).
u Screw fixing ring into place until
tight. Do not over tighten (fig.9).
u Make the cylindrical outlet cover (fig.
10).
Form kebbe as illustrated below and
deep fry.
CUTTING SLICE/SHRED/STRIP
u Press the fasten button, hold the
head and insert it into the inlet (when
inserting, please pay attention the head
must be slanted as per arrow indicated
on the top, see fig. 8), then move the
head anticlockwise, so that the head
being fastened tightly. There will be
locked when you heard a voice of “KA”
(fig. 2).
u Put the cutting attachments “slice
cutter” or “shredded cutter” or “strip
cutter” into the cutting head. Note:
must be on place (fig. 9).
u The switch I/II knob to “I”, the
switch ON/O/R knob to “ON” position,
when you cutting. Put the vegetable into
vegetable cutting head, and then push
down the vegetable pusher with 5N
power (fig. 10).
u After use, switch the unit off and
unplug it from the power supply.
MAKING SAUSAGE
u Before starting, please assemble
sausage attachment as per follow-
ing (fig. 11).
TOMATO JUICER
u Revolve the adjusted nail to the
front of tomato juicer bracket (fig. A).
u Put the fix ring through the tomato
juicer bracket (fig. B).
u Pack the attachments like fig. C.
u Put the containers under tomato
juicer attachment like fig. D to collect
juice and residue. Cut the tomato into
fix meat grinder like head size, then
press them gently, it can short the
working time.
u Adjust the screw can make the
juice dense or thin.
