Low Row Assembly Guide: Getting Started 3
Hardware Kit (not to scale)
The following pieces of hardware are provided on a shrink-wrapped card. Each part is labeled on the card for easy reference.
Table 1. Hardware kit contents
Fastener
Quantity
Socket head cap screw (M12 x 35 mm) 12
Flat washer (9 mm internal diameter) 5
Buttonhead cap screw (M8 x 15 mm) 1
Set screw (M8 x 6 mm) 8
Flat washer (13 mm internal diameter) 12
Hex head cap screw (⁵₁₆-inch x 1¹₂-inch) 4
