Inside View of Your Computer
CAUTION:
Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
CAUTION:
To avoid electrical shock, always unplug your computer from the
electrical outlet before removing the computer cover.
NOTICE:
Be careful when opening the computer cover to ensure that you do not
accidentally disconnect cables from the system board.
1
drives bay
(CD/DVD, floppy, and hard drive)
2
power supply
3
system board
4
card slots
5
heat sink assembly
6
front I/O panel
1
2
3
4
5
6
